Model: Drip Coffee Bag Packaging Machine FG-70
Product Performance
Max. BPM: Up To 70 bags/min
Packing Range: 5-15g
Packing Accuracy: ±0.1g
Inner Bag Size: 74mm*90mm
Outer Bag Size: 120mm*100mm
The main control system is a 5U high-speed computing PLC imported from Japan and is jointly developed and written by programmers from Japan's Mitsubishi PLC Company. The system has a built-in Ethernet interface and a 4-axis 200kHz high-speed positioning function that is 150 times higher than the ordinary PLC in the market. This drip coffee bag machine can realize the synchronous and coordinated operation of the inner and outer bag materials to achieve high-speed, safe and stable operation.
| Model | FG-70 | ||
| Measurement Method | Sliding Volume | ||
| Production Efficiency | 60-70 bags/min | ||
| Packing Weight | 5-15g/Pack (Special Specifications Can Be Customized) | ||
| Packing Accuracy | ±0.1g (Depending On Material Conditions) | ||
| Control System | Servo Controller + Color Touch Screen | ||
| Common Inner Bag Dimensions | 74*90mm | ||
| Common Outer Bag Dimensions | 100*120mm | ||
| Inner Bag Material | Non-Woven Fabric, Nylon Filter Cloth, Corn Fiber | ||
| Outer Packaging Materials | Composite Film, Pure Aluminum Film, Paper Film And Other Heat-Sealable Films | ||
| Inner Bag Sealing Method | Ultrasonic Sealing | Inner Bag Sealing Form | Three Side Sealing |
| Outer Bag Sealing Method | Heat Seal | Outer Bag Sealing Form | Three Side Sealing |
| Power Supply | 3.5kW/220V | Air Consumption/Pressure | 6-8bar/0.6mm³/min |
| Machine Dimensions (L.W.H) | 1490*1010*2725mm | Machine Weight | 950kg |
| Optional Devices | Vacuum Feeder | Nitrogen Generator | TTO Printer |
1. The 3D integrated printing bag.
2. The coffee machine packaging 's former is ensure smooth bag making and beautiful forming.
3. The slide doser adopts plasma anti stick technology.
4. Material contact parts are coated with antibacterial sodium coating layer technology.
5. Stable performance with 6 servos. Higher nitrogen filling residual oxygen rate than industry standard.
6. Follow-up film feeding, automatically match cylinder and motor without parameter adjustment.
7. Automatic alarm and shut down for production and safety errors.
