MD-160-06S Pyramid Tea Inner and Outer Bag Packaging Machine

Model: Pyramid Tea Bag With Overwrap Packaging Machine MD-160-06S

Product Performance


  • Max. BPM: Up To 50 bags/min

  • Packing Range: 1-20g

  • Packing Accuracy: ±0.2g

  • Measuring Method: Load-Cell Weigher

Contact
  • triangle tea bag packing machine
Description Parameters Features

Description of MD-160-06S Pyramid Tea Inner and Outer Bag Packaging Machine

This machine adopts an electronic load cell for measurement, suitable for materials such as green tea, black tea, flower tea, coffee, Chinese tea, health tea, herbal tea, granules, etc...Fast and easily changing materials. This tea bag packaging machine can make rectangular and triangular tea bags from Nylon, PET, Nonwoven, and PLA films. It works automatically with feeding, counting, bagging, sealing, cutting, and so on.

Parameters of MD-160-06S Pyramid Tea Inner and Outer Bag Packaging Machine

ModelMD-160-06S
Measurement MethodLoad-Cell Weigher
Production Efficiency30-50 bags/min
Inner Bag Size120mm, 140mm, 160mm (Customizable)
Packing Accuracy±0.2g (Depending On Material Conditions)
Power Supply2kW/220VAir Consumption/Pressure6-8bar/0.4m³/min
Machine Dimensions (L.W.H)

3491*1350*2213mm

Machine Weight887kg


Features of MD-160-06S Pyramid Tea Inner and Outer Bag Packaging Machine

1. Max. Bpm up to 50.

2. One click switching for triangular bags and flat bags.

3. Multi-formulas for different materials packaging.

4. Automatic alarm and shut down for production and safety errors.

5. Split structure for easy detection of defective products.

6. Adopts servo module for material poking to make more precise poking positions.
